Código: DL00202
Fabricante: Dallas Avionics
Mercados:
*Regulated DC to DC power booster converter PWM designed, MIL SPEC designed *FAA TSO C-71 approved *Wide input voltage (9.0-16.1)VDC for emergency operation *Extremely low standby (no load) power consumption, to minimize battery drain during emergency use *Solid construction with encapsulation potting for severe vibration *Rugged MIL-SPEC environment *Choice for output current of 6 AMP, 12 AMP, 24 AMP, 36 AMP and 48 AMP continuously, at 28VDC *Extremely stable regulated output voltage, in all harsh environmental conditions *State of the art PWM designed *High efficiency extremely low heat *Circuit protections include output over current *Output short circuit *Output over voltage *Low input voltage shut down *Soft start *Input reverse polarity *May be installed in a pressurized or non-pressurized area *Controlled or non-controlled temperature at altitudes up to 55,000' *All necessary accessories are provided, including mating MS connector plug and MS cable clamp *Smallest size available: (1.91" W x 4.84" H x 6.78" L) *Lightest weight available: (2.3 lbs.) *Environmental tested per RTCA DO-160d *3-year extended warranty
